Description
Produce eye-catching displays
See outstanding image quality. Work with the wide color gamut and smooth transitions delivered by this matte polypropylene material and produce quality prints from line drawings to photo-quality POP displays.
Gain efficiency
Help keep your production process moving smoothly. This easy-to-use film features a permanent self adhesive for secure, reliable mounting.
Make the versatility of this material work for you
ICC profiles help you get the right color, right away. Take advantage of compatibility with HP dye and pigment inks. Offer over 50 years unlaminated indoor display permanence,1 on this versatile, easy-to-use printing material.
Benefits
- Outstanding image quality for day-to-day production
- Instant dry time
- A permanent self-adhesive for secure, reliable mounting
- Compatible with both HP dye- and pigmentbased inks
- 50+ years unlaminated indoor display permanence on HP Designjet Z-series printers
- Broad HP Designjet printer compatibility (Requires 2-inch spindle for compatibility with the HP Designjet L25500 and L26500 Printer series.)
Applications
- POP and retail displays
- Trade show and event displays
- Temporary exhibitions
- Architecture competitions
Sizes available
- CH022A: 610 mm x 30.5 m (24" x 100')
- CH024A: 914 mm x 61 m (36" x 200')
- CH025A: 610 mm x 30.5 m (24" x 100')
- CH027A: 1524 mm x 30.5 m (60" x 100')
Technical Specifications
- Weight (without liner): 120 g/m1 per ISO 536 Test Method
- Weight (with liner): 168 g/m1 per ISO 536 Test Method
- Thickness (without liner): 180 microns/7.1 mil per ISO 534 Test Method
- Thickness (with liner): 215 microns/8.5 mil per ISO 534 Test Method
- Opacity (with liner): Greater than 96% per TAPPI T-425 and ISO 2471 Test Methods
- Brightness (with liner): 101% per ISO 2470 Test Method
- Whiteness (without liner): Greater than 120 per ISO 11476 Test Method
- Whiteness (with liner): 150 per ISO 11475 Test Method
- Finish: Matte
- Operating temperature: 15 to 35° C / 59 to 95° F
- Operating humidity: 20 to 80% RH
- Display permanence (Indoor home or office): 50+ years unlaminated with Original HP 771 Vivid Photo Inks, Original HP 91 Photo Inks, or Original HP 70 Photo Inks on the HP Designjet Z3200 Photo Printer series
- Water resistance: Moderately water resistant with Original HP 771 Vivid Photo Inks, Original HP 91 Photo Inks, or Original HP 70 Photo Inks on the HP Designjet Z3200 Photo Printer series; lamination recommended with Original HP dye inks
- Dry time: Less than 2 minutes (at 23° C, 50% RH)
- Lamination: Yes
- Shelf life: 2 years, unopened in original packaging
- Storage temperature: 15 to 35° C / 59 to 95° F
- Storage humidity: 15 to 30% RH
- Country of origin: Product of China
- Warranty: HP large format printing materials are free from defects in materials and workmanship. For warranty statement, please see HP Media Warranties.
