Beschreibung
This Valve is suitable for Swissqprint Oryx printers. This is the original part (number 912-000001-003).
Technical Specifications
- Flow Rate: up to 6 SLPM
- Voltage (VDC): 12
- Maximum Flow Rate: 6 SLPM
- Maximum Operating Pressure: up to 30 psi, 2.0 bar
- Orifice Size: 0.030 inch, 0.75 mm
- Maximum Operating Temperature:122 °F, 50 °C
- Minimum Operating Temperature: 32 °F, 0 °C
- Function: 3-Way, Universal
- Cycles per Lifetime: up to 25 Million
- Actuation Type: Solenoid
- Operation Type: Electronic
- Valve Configuration Type: 3 Way Universal
- Control Method: Current or Voltage
- Power Consumption: 1.0 W
- Input Voltage: 12 VDC
- Electrical Connection: Long Pins
- Body Material: PBT (Polybutylene Terephthalate)
- Seal Material: FKM
- Length: 0.92 inch, 24 mm
- Width: 0.31 inch, 8 mm
- Elastomer Material: FKM
- Height: 0.35 inch, 9 mm
- Weight: 0.16 oz, 4.5 g
- Response Time: < 20 ms
- Leak Rate: < 0.016 cm3/min
- Port Connection: Barb
- Mounting Type: PC Pins, Manifold (Gasket Required)
- Application Pressure Requirement: 30 psi (.030" orifice)
- Connection Type: Retention Pin, Mounting Screw
- For Fluid Type: Gases
- Connection Size: 22 AWG (Retention Pin); 0-80 x 1/2" Binding Head, Phillips Screw
- Industry Application: Portable Equipment, Blood Pressure Monitoring, Wound Therapy, Air and Oxygen Delivery, Sensor Zeroing
- Configuration: n/a
- Electrical Connection: Long Pins
Drucker Kompatibilität:
SwissQprint Oryx
