Description
Hitachi / Ricoh GEN3E1 (MH1801/1901) printhead is designed for the HP Scitex Turbojet printers. It is a compact, yet robust printhead for fast speed and high quality printing with an isolated ink-chamber design and an all metal construction for industrial applications.
This is the original HP Scitex Turbojet printhead (part number 338036-001 replacing CW903-62443 and 502000269).
The following items are expressly excluded from warranty coverage:
- defects related, in any way, to the use of non-original inks
- clogged, missing or deviated nozzles
- defects related to misuse, abuse, accident, neglect, lack of use, or improper storage when not in use for extended periods
- defects related to failure to perform periodic maintenance as specified in the user documentation; operation for unintended purposes
- defects related to improper loading of media
- all other defects, failures or damage not considered manufacturing defects
- defects related to third-party applications, software, parts, components, or peripheral devices, including any bulk ink system.
- defects that are merely cosmetic in nature
Product Specifications
- Active nozzles: 96
- Piezo type: D33 stacked PZT
- Print swathe width: 17.2 mm
- Nozzle pitch: 0.6809 mm
- Drop velocity: 8 m/s
- Printhead weight: 60 g
- Dimensions: 120 x 35 x 8 mm
- Life: 100 billion actuations per nozzle
- Drop volume: 30 or 65 pl
- Firing frequency: up to 20 kH
- This printhead carries a manufacturer warranty.
- Country of origin : United States
Compatibilité Imprimante:
HP Scitex TJ8300, HP Scitex TJ8350, HP Scitex TJ8500, HP Scitex TJ8550, HP Scitex TJ8600, HP Scitex TURBOjet
