Description
The Epson I3200-U1 UV is a cost-effective 1.33inch-wide MEMs head series providing high productivity and high image quality with 600dpi high-density resolution. This printhead is suitable for UV inks. It is unlocked. We recommend to change the head cables when installing a new printhead. It is aslo known as I3200-S1 HD.
Warranty: due to the nature of DTF inks, we cannot accept returns, exchanges or refunds once the printhead has been installed. All sales are final.
Specifications :
- Ink Type : UV
- Type : PrecisionCore MicroTFP printhead
- Width x Depth x Height: 69.1 x 59.4 x 35.6 mm
- Weight : 82g
- Number of nozzle : 3200
- Nozzle pitch/nozzle row : 1/300 inch
- Nozzle rows: 8 rows
- Nozzle Resolution : 300 noi/row 600 npi/2 rows
- Max. number of colour inks : 4 colours
- Effective print width : 33.8 mm (1.33 inches)
- Droplet ejection performance :
Binary : 5 plat 43.2 kHz
3 levels grey scale : 6, 12.5 pl at 21.6 kHz
4 levels grey scale 3.8, 6.2, 9.3 pl at 21.6 kHz
- Viscosity range : 5-7 mPa·s
- This printhead carries a manufacturer warranty.
- Country of origin : Japan
Compatibilité Imprimante:
Audley ADL6003UV, ColDesi UV 300H3F, ColDesi UV 500H3F, ColDesi UV 800H3F, ColDesi UV DTF 12H1R, Infiniti FY-1800H, Infiniti FY-3200MS/I4, Infiniti FY-A3701, Infiniti FY-A3701F, Infiniti FY-UV1603, Infiniti FY-UV1800W, Infiniti FY-UV1803, Nocai NC-Cyclone-400, Nocai NC-UV0609MAX, Signstar BT-1804UN, Signstar UV-6090, Signstar UX-1802, Sinocolor FB-0906D, Sinocolor FB-2513S, Sinocolor HUV-2000S, Sinocolor HUV-2600S, Sinocolor HUV-3200S, Sinocolor UE-2000D, Sinocolor UR-2000S, Sinocolor UR-3200S, Sinocolor UR-5000S, Sinocolor UV-1260S, Sinocolor UV-740S, Sublistar UV 6090F Turbo, Sublistar UV-300VB, Sublistar UV-604, Sublistar UV-60R Star IV, Sublistar UV-60R Turbo, Textek UV-F604, Xante X-33
