Description
The Epson i1600-E1 1.33 inch-wide MEMs printhead provides high productivity and high image quality with 600dpi high-density resolution. This printhead is compatible with ecosolvent inks. It is unlocked and should fit most i1600-E1 based printers. We recommend to change the head cables when installing a new printhead.
Warranty: due to the nature of DTF inks, we cannot accept returns, exchanges or refunds once the printhead has been installed. All sales are final.
Specifications :
- Ink Type : Eco-solvent
- Type : PrecisionCore MicroTFP printhead
- Width x Depth x Height: 69.1 x 59.4 x 35.6 mm
- Weight : 80g
- Number of nozzle : 1600
- Nozzle pitch/nozzle row : 1/300 inch
- Nozzle rows: 4 rows
- Nozzle Resolution : 300 noi/row 600 npi/2 rows
- Max. number of colour inks : 4 colours
- Effective print width : 33.8 mm (1.33 inches)
- Droplet ejection performance :
Binary : 5pl at43.2kHz
3 levels grey scale : 6, 12.5 pl at 21.6 kHz
4 levels grey scale 3.8, 6.2, 9.3 pl at 21.6 kHz
- Viscosity range : 5-7 mPa･s
- Positioning mechanism: Reference hole
- This printhead carries a manufacturer warranty.
- Country of origin : Japan
Compatibilité Imprimante:
ColDesi UV DTF 24H3R
