Xaar Irix PRO 80 - XP12800064

Genuine Xaar Irix Pro printhead with an 80pL drop size. The insulator tag is purple, which is how this head is identified against the 40pL version's light grey tag. 128 active nozzles at 185 NPI density give a 17mm print swathe, running at up to 5.5 kHz and a linear speed of 0.78 m/s at 180 DPI. Xaar's AcuDrp calibration tunes each nozzle for drop volume and velocity, keeping print uniformity within +/- 0.10 m/s drop velocity variation and max angular deviation of 1 degree. The larger drop suits applications needing higher lay-down or coverage rather than fine detail. Compatible with oil, solvent and water-based ink systems; print distance under 10mm. Ink connections are 3.1mm, so use 3mm ID tubing, chosen to suit your ink.

Xaar Irix Product Datasheet

DIGIPRINT SUPPLIES is an authorised Xaar reseller. This is a genuine Xaar product and carries Xaar's 12-month warranty.

Product specification:

• Active nozzles: 128
• Nozzle density (NPI): 185
• Print swathe (mm): 17
• Dimensions (mm): 37.2 x 11.3 x 40.8
• Mass (g): 15.5
• Colour of insulator: Purple
• Drop size (pL): 80
• Drop velocity (m/s): 5
• Max frequency (kHz): 5.5
• Linear speed (m/s @ 180 DPI): 0.78
• Print distance (mm): <10
• Max angular deviation (degrees): 1
• Drop velocity variation 3σ (m/s): +/- 0.10
• Country of origin: United Kingdom

Warranty exclusions:

The following items are expressly excluded from the warranty coverage:

• defects related to the use of non-original inks
• clogged, missing or deviated nozzles
• defects related to misuse, abuse, accident, neglect, lack of use, or improper storage when not in use for extended periods
• defects related to failure to perform periodic maintenance as specified in the user documentation; operation for unintended purposes
• defects related to improper loading of media
• all other defects, failures or damage not considered manufacturing defects
• defects related to third-party applications, software, parts, components, or peripheral devices, including any bulk ink system
• defects that are merely cosmetic in nature
