Beschreibung
This Toshiba CF1B printhead is suitable for printers such as Mimaki UJF-7151 Plus. This is the original Toshiba part number CF1B.
We recommend to change the head cables when installing a new printhead.
The following items are expressly excluded from warranty coverage:
- defects related, in any way, to the use of non-original inks
- clogged, missing or deviated nozzles
- defects related to misuse, abuse, accident, neglect, lack of use, or improper storage when not in use for extended periods
- defects related to failure to perform periodic maintenance as specified in the user documentation; operation for unintended purposes
- defects related to improper loading of media
- all other defects, failures or damage not considered manufacturing defects
- defects related to third-party applications, software, parts, components, or peripheral devices, including any bulk ink system.
- defects that are merely cosmetic in nature.
Specifications
- Print Method: Drop on demand piezo
- Print Width: 53.7mm
- Number of channels: 636
- Resolution: 300dpi / 84.5 micron
- Grayscale level: 8-levels/0~7drops
- Drop Volume: 6 - 42pl
- Maximum dot frequency: 4.97kHz/7 drops
- Linear speed: 24m/min (at max dpd)
- Driving voltage: 14 - 31V
- Drop velocity: 7 - 9 (m/s)
- Weight: 161g (185g with positionning plate)
- Dimension: 94 (W) x 79 (D) x 26 (H) mm / 111 (W) x 79 (D) x 34 (H) mm with repositionning plate
- Jettable fluids: UV-curing, oil-based
- This printhead carries a manufacturer warranty.
- Country of origin : Japan
